Boiler industry Superheaters and reheaters small radius heat exchange are good quality

Boiler Reheater Description

1. Superheaters and reheaters in utility boilers increase the temperature of saturated or near-saturated steam in order to increase the thermodynamic efficiency of the power cycle or to provide the desired process conditions.

2. In general terms, they are simple single-phase heat exchangers with steam flowing inside the tubes and flue gas passing outside the tubes, generally in crossflow.

3.The key criteria in the design of these heat exchangers are:

• Limiting tube metal temperatures to below acceptable values to meet allowable stress and corrosion - erosion limits
• Controlling steam outlet temperatures within the specified level over the range of boiler operationg conditions
• Maintaining pressure drop on the steam side within allowable limits(especially for high-pressure subcritical boilers)

What is use of a reheater in a thermal power plant?

1. High pressure steam is expanded in turbine, moisture content of exhaust steam increases, which creates problem at exit end blades.

2. So reheat type turbine is most commonly used for large capacity turbine using high pressure steam. Steam after expanding at HP Turbine is sent to boiler for further heat addition or reheat.

3. This steam is called as cold reheat. Cold reheat is heated at reheat is then sent to IP/LP Turbine where it expands further.

4. Single and double reheat turbines are commonly used for power generation.

Performance feature

1. The custom of boiler
With a mature technical team, Dehai boiler can be designed according to the smoke and steam parameters provided by users to achieve the best effect.

2. Low resistance
The boiler body adopts the design of uniform flow rate and low flow rate, and the body resistance is less than 900Pa at the design working condition, which is conducive to the combination with other equipment and to reduce the power consumption of the system.

3. long life
It has long service life, simple operation and maintenance, economic safety and reliability. It is fully applicable to float glass furnace production line using heavy oil or natural gas fuel.

4. Reliably Sealing
The light fender all-welded furnace wall structure is adopted, and the connection between the fender and the steel frame is of flexible sealing structure, so as to ensure that the joint between the fender and the steel frame is not diswelded due to thermal expansion during boiler operation.The whole welded sealing structure of the pipe bundle through the wall of the guard plate furnace reduces the air leakage of the boiler.

Differences

Small Radius

    Dehai Boiler is a manufacturer of A-class boiler(Power station boiler,industrial boiler,HRSG,waste-to-energy boiler,biomass boiler) and correlated A-class pressure parts intergrating the design,fabrication,installation,repair and mainteance.

Dehai has ISO9001:2008 certificate issued by France AFAQ-EAQA Ltd,A-class boiler manufacturing license,ASME S Stamp and U Stamp authorized certificate.

    Through effective management system and high quality products,Dehai became the qualified supplier of many famous boiler factories and energy companies and has won a lot of stable customers both domestic and abroad ,such as :Amec Foster Wheeler,Alstom,Dongfang Boiler,Harbin Boiler,Hangzhou Boiler,etc.

    Based on the business idea of "High quality for survival and perfect service for development",we shall care for customers' demand and keep improving our work permanently. To create Dehai brand,is to serve clients with our improved products and better performance.

    Dehai is located in Economic and Technological Development Zone,Zhangjiagang City,Jiangsu Province. S38 highway Zhangjiagang exit is about 1.5 kilometers to the north of our company and the traffic is very convenient.
