Steam Superheaters and Reheaters

1. The superheaters and reheaters are tube bundles located in the flue gas stream that increase the temperature of the saturated steam, which is produced in the furnacewaterwalls.

2. These tubes are constructed from steel alloy material because of their high operating temperature. The main difference between superheaters and reheaters is the steam pressure.

3. In a typical drum boiler, the superheater outlet pressure might be 2700 psig while the reheater outlet pressure might only be 580 psig. They are used to help control steam temperatures, control steam flow pressure loss, and optimize heat recovery.

Reheater Function

1. Therefore the number of reheat stages can not be many as the pressure drop will reduce efficiency of thermal cycle.The steam pipes and reheater coils are to be so designed to limit the drop to 2–3%.

2. The control valves in reheat steam path is not desirable.Systems using HP LP bypass require these valves to control steam flow during bypass operation.

3. The efficiency of the Reheat cycle can be improved by increasing the pressure and temperature of steam entering into the turbine. As the initial pressure increases the expansion ratio of the turbine also increases and the steam becomes quite wet at the end of expansion.

Details

1. Convection superheater/reheater heating surfaces are placed above or behind the banks of water tubes at the rear of the radiant heatingsurfaces to protect them from combustion flames and high temperatures.

2. The main mode of heat transfer between the flue gasesand the convection superheater/reheater tubes is convection. With an increase in steam demand, both fuel and air flow increase, resulting in an increase in flue-gas flow.

3. As a result, convective heat transfer coefficients increase both inside and outside the tubes. The overall heat transfer coefficient between gas and steam hence increases faster than the increase in mass flow rate of steam.

Differences

Product Display

    Dehai Boiler is a manufacturer of A-class boiler(Power station boiler,industrial boiler,HRSG,waste-to-energy boiler,biomass boiler) and correlated A-class pressure parts intergrating the design,fabrication,installation,repair and mainteance.

Dehai has ISO9001:2008 certificate issued by France AFAQ-EAQA Ltd,A-class boiler manufacturing license,ASME S Stamp and U Stamp authorized certificate.

    Through effective management system and high quality products,Dehai became the qualified supplier of many famous boiler factories and energy companies and has won a lot of stable customers both domestic and abroad ,such as :Amec Foster Wheeler,Alstom,Dongfang Boiler,Harbin Boiler,Hangzhou Boiler,etc.

    Based on the business idea of "High quality for survival and perfect service for development",we shall care for customers' demand and keep improving our work permanently. To create Dehai brand,is to serve clients with our improved products and better performance.

    Dehai is located in Economic and Technological Development Zone,Zhangjiagang City,Jiangsu Province. S38 highway Zhangjiagang exit is about 1.5 kilometers to the north of our company and the traffic is very convenient.
