Corrosion Resistance Water Wall Panels For Power Plant Steam Boiler radiation heat transfer

Corrosion Resistance Water Wall Panels Advantages

1. Ensure the sealing of furnace wall and reduce air leakage in combustion chamber.
2. Realize full water cooling in the combustion chamber, which is conducive to preventing coking under the condition of intensified combustion.
3. Low heat storage capacity, fast heating and cooling of the combustion chamber, which can shorten the cooling time of the boiler starting and stopping.
4. It is suitable to use tube-laying furnace wall, which greatly reduces the load of boiler frame and facilitates suspension.
5. Compared with the light pipe, the heat absorption capacity of the pipe is improved.
6. Improve the pre-assembly degree of boiler components, facilitate and reduce the installation workload.

Carbon Steel Membrane Water Wall Panels Functions

1. Protect the furnace wall and reduce the erosion and damage of high temperature smoke and slag in the furnace to the furnace wall.
2. After installing water wall, the temperature of inner wall and flue gas temperature in furnace are greatly reduced, which can effectively prevent slag forming on furnace wall and heating surface, and reduce thickness and weight of furnace wall.
3. Modern large boiler, the use of furnace wall and water-cooled wall tube together to form a pipe-type or tube on the furnace wall, that is, the use of water-cooled wall tube suspended furnace wall.
4. The high temperature flame in the furnace conducts heat to the water-wall tube, mainly by radiation.
The radiative heat transfer intensity is proportional to the fourth power of the absolute gas temperature.
5. Because the gas temperature in the furnace is very high, so, the water wall tube in the furnace to absorb radiation heat transfer is very strong, is the main boiler evaporation heating surface.
6. For high pressure and ultra-high pressure boilers, radiant superheater is usually arranged on the top of the furnace;
7. For the dc boiler, part of the preheating heating surface (equivalent to economizer) and overheating heating surface (equivalent to superheater) are often arranged in the water wall;
8. While the supercritical dc boiler, because there is no evaporation heating surface, the water wall is only used to heat water and superheated steam.

Membrane Water Wall Panel Product details

1. Water wall panels with pins usually laid vertically on the inner wall of the furnace wall, it is mainly used to absorb the radiant heat emitted by the flame and high-temperature flue gas in the furnace.

2. It is the main type of evaporating heating surface of all kinds of modern boilers and the basic component of boiler water circulation loop.

3. Because of both cooling and protection of the furnace wall, so the name.

4. The water wall was originally designed not to be heated, but to cool the furnace from high temperature damage.

5. Later, because of its good heat exchange function, it gradually replaced the steam drum as the main heating part of the boiler.

Product Display

    Dehai Boiler is a manufacturer of A-class boiler(Power station boiler,industrial boiler,HRSG,waste-to-energy boiler,biomass boiler) and correlated A-class pressure parts intergrating the design,fabrication,installation,repair and mainteance.

Dehai has ISO9001:2008 certificate issued by France AFAQ-EAQA Ltd,A-class boiler manufacturing license,ASME S Stamp and U Stamp authorized certificate.

    Through effective management system and high quality products,Dehai became the qualified supplier of many famous boiler factories and energy companies and has won a lot of stable customers both domestic and abroad ,such as :Amec Foster Wheeler,Alstom,Dongfang Boiler,Harbin Boiler,Hangzhou Boiler,etc.

    Based on the business idea of "High quality for survival and perfect service for development",we shall care for customers' demand and keep improving our work permanently. To create Dehai brand,is to serve clients with our improved products and better performance.

    Dehai is located in Economic and Technological Development Zone,Zhangjiagang City,Jiangsu Province. S38 highway Zhangjiagang exit is about 1.5 kilometers to the north of our company and the traffic is very convenient.
