Boiler Superheater High Quality Steam Superheater Specification Superheater Coils Exported

Boiler Superheater Structural character

1. The waste heat boiler is outdoor horizontal smoke tube boiler and is composed of boiler shell and inlet & outlet smoke box. Gas is diverted by inlet smoke box and washes smoke tube in vertical direction and finally converges and flows out from outlet smoke box.

2. In order to avoid a direct wash to front tube sheet by high-heat gas, a refractory protection is cast on the surface of front tube sheet and a refractory protective tube is installed on the inlet of the smoke tube.

3. Steam space is located on the upper part of boiler shell smoke tube, and a wire mesh demister is installed on the steam outlet for steam-water separation.

4. The whole waste heat boiler is supported by two saddles; one along the direction of the gas flow is fixed support and is fixed on the foundation by eight anchor bolts, others are sliding supports.

Brief Introduction

1. Generally 30 ~ 60 mm.The most common type of flow superheater is serpentine tube.It has a more intensive tube group, decorate in 450 ~ 1000 ℃ flue of the flue gas temperature, flue gas of vertical and lateral erosion.The flue gas mainly transfers the heat to the pipe by convection, and some of the heat is absorbed by radiation.

2. The plate-type superheater consists of a plurality of tube screens, arranged in the upper part of the furnace or at the outlet, belonging to the radiation or semi-radiation type superheater.The former absorbs radiant heat from the furnace flame, while the latter also absorbs some convection heat.

Technical Parameter

    Dehai Boiler is a manufacturer of A-class boiler(Power station boiler,industrial boiler,HRSG,waste-to-energy boiler,biomass boiler) and correlated A-class pressure parts intergrating the design,fabrication,installation,repair and mainteance.

Dehai has ISO9001:2008 certificate issued by France AFAQ-EAQA Ltd,A-class boiler manufacturing license,ASME S Stamp and U Stamp authorized certificate.

    Through effective management system and high quality products,Dehai became the qualified supplier of many famous boiler factories and energy companies and has won a lot of stable customers both domestic and abroad ,such as :Amec Foster Wheeler,Alstom,Dongfang Boiler,Harbin Boiler,Hangzhou Boiler,etc.

    Based on the business idea of "High quality for survival and perfect service for development",we shall care for customers' demand and keep improving our work permanently. To create Dehai brand,is to serve clients with our improved products and better performance.

    Dehai is located in Economic and Technological Development Zone,Zhangjiagang City,Jiangsu Province. S38 highway Zhangjiagang exit is about 1.5 kilometers to the north of our company and the traffic is very convenient.
